Material Testers

Material testers fall into two categories; motor operated and hydraulic pump operated. Motor operated are available to 300 kN and hydraulically operated are available from 200 kN through 4000 kN capacities.

Lower capacity models are table top and high capacity are floor mount systems. Some of these can be operated from an internal program, however, to realize the full potential software is necessary. Many accessories are available and all support extensometers and LVDT devices. Software will also support other external devices such as weighing scales, micrometers, and calipers with electronic data output for data collection into the software. Extension and force measurement is built in with the latter, utilizing plug and play load cells.

Lloyd Material Testers
ft1 FT1 (for accurate measurement of static and kinetic coefficient of friction) -The Lloyd Instruments FT1 coefficient of friction tester accurately measures static and kinetic coefficient of friction.  These values are of importance in a wide range of industries including blown film, plastic sheet, paper, packaging, and coating manufacture.

The FT1 is a bench mounted, single lead screw dedicated friction tester. A friction table is mounted directly on the machine with a full set of accessories included to perform tests conforming to the requirements of ASTM D1894, ISO 8295 and TAPPI T549.  The tester is supplied with these three standards pre-programmed, with a total of ten set-ups available for custom configuration and has USB output.



Material Testing Machines- Single Column Bench Mounted
ls1

LS1 1kN (225 lbf)

  • Uses high accuracy interchangeable XLC Series load cells (< 0.5% of reading)
  • Large working area - 180 mm throat for large specimens
  • Crosshead travel 500 mm (19.7 in) standard, 800 mm extended (31.5 in)
  • Speed range 0.01-2032 mm/min (0.0004-80 in/min)
  • Flexible work surface configurations (Base table (supplied as standard) and optional expanded work table, T-slot table and drip tray)
  • Data sampling rate 8 kHz
LS2.5

LS2.5

  • Uses high accuracy interchangeable YLC load cells (±0.5% from 1% to 100% of load cell value)
  • Crosshead travel 1400 mm (55 in)
  • Speed range 0.01 - 2032 mm/min (0.0004 to 80 in/min)
  • Data sampling rate 8 kHz
  • Saves up to 600 test results
  • 10 programable test set-ups
  • High-resolution backlit LCD display with intuitive operator interface
  • Flash memory upgradeable
ls5 LS5 5 kN (1124 lbf)
  • Simple to set up, operate and maintain
  • Load measuring system exceeds the requirements of all recognized international standards
  • Uses high-accuracy interchangeable YLC load cells (±0.5% from 1% to 100% of load cell value)
  • Crosshead travel 800 mm (31.5 in)
  • Extended version available with travel up to 1400 mm (55 in)
  • Speed range 0.01 - 1016 mm/min (0.0004 to 40 in/min)
  • Data sampling rate 8 kHz
  • Saves up to 600 test results
  • 10 programable test set-ups
  • High-resolution backlit LCD display with intuitive operator interface
  • Flash memory upgradeable
Material Testing Machines - Twin Column Bench Mounted
lr5k LR5KPlus 5 kN (1124 lbf)
  • Crosshead travel 975 mm (38.4 in)
  • Extended versions available with travel up to 1463 mm (57.6 in)
  • Speed range 0.01 - 1016 mm/min (0.0004 to 40 in/min)
  • Data sampling rate 8 kHz
  • Can be mounted above floor standing compression cage for large sample/complete assembly testing
lr10k LR10KPlus 10 kN (2248 lbf)
  • Crosshead travel 950 mm (37.4 in)
  • Extended versions available with travel up to 1435 mm (56.5 in)
  • Speed range 0.01 - 508 mm/min (0.0004 to 20 in/min)
  • Data sampling rate 8 kHz
  • Can be mounted above floor standing compression cage for large sample/complete assembly testing
ez20 EZ20 20 kN (4496 lbf)
  • Crosshead travel 870 mm (34.3 in)
  • Speed range
    • Up to 20 kN: 0.001 - 508 mm/min (0.00004 to 20 in/min)
    • Up to 10 kN: 0.01 - 1016 mm/min (0.0004 to 40 in/min)
  • Data sampling rate 8 kHz
  • Can be mounted above floor standing compression cage for large sample/complete assembly testing
lr30k LR30KPlus 30 kN (6744 lbf)
  • Crosshead travel 870 mm (34.3 in)
  • Extended versions available with travel up to 1370 mm (54 in)
  • Speed range 0.001 - 508 mm/min (0.00004 to 20 in/min)
  • Data sampling rate 8 kHz
  • Can be mounted above floor standing compression cage for large sample/complete assembly testing
lr50k LR50KPlus 50 kN (11241 lbf)
  • Crosshead travel 855 mm (33.7 in)
  • Extended versions available with travel up to 1355 mm (53.4 in)
  • Speed range 0.001 - 508 mm/min (0.00004 to 20 in/min)
  • Data sampling rate 8 kHz
  • Can be mounted above floor standing compression cage for large sample/complete assembly testing
ls100 LS100Plus 100 kN (22481 lbf)
  • Crosshead travel 824 mm (32.4 in)
  • Speed range
    • Up to 50 kN; 0.001 - 254 mm/min (0.00004 to 10 in/min)
    • 50 kN to 100 kN: 0.001 - 101.6 mm/min (0.00004 to 4 in/min)
  • Data sampling rate 8 kHz
  • Working width between the columns 404 mm (16 in)
  • Bench mounted model
ez 50 EZ50 50 kN (11241 lbf)
  • Crosshead travel 855 mm (33.7 in)
  • Speed range 0.01 - 254 mm/min (0.0004 to 10 in/min)
  • Data sampling rate 8 kHz
  • Can be mounted above floor standing compression cage for large sample/complete assembly testing
Material Testing Machines - Twin Column Floor Standing
lr100k LR100KPlus 100kN (22481 lbf)
  • Crosshead travel 1150 mm (45.3)
  • Speed range 0.001 - 508 mm/min (0.00004 to 20 in/min)
  • Data sampling rate 8 kHz
  • Working width between the columns 620 mm (24.4 in)
  • Floor standing model
lr150k LR150KPlus 150 kN (33722 lbf)
  • Crosshead travel 1150 mm (45.3 in)
  • Speed range 0.001 - 254 mm/min (0.00004 to 10 in/min)
  • Data sampling rate 8 kHz
  • Working width between the columns 620 mm (24.4)
  • Floor standing model
Materials Testing Software
plus

NEXYGENPlus multi-lingual materials testing software is the hub of the Lloyd Instruments Plus Series materials testing system . This extraordinarily easy to use and flexible software, allows the operator to control and monitor all aspects of the system from a single front end, ensuring fast, reliable and powerful testing and data analysis for tensile, compression, peeling, tearing, creep, relaxation and  flexural test applications.

With NEXYGENPlus software, the user can simply select from the extensive library of pre-defined test set-ups based on international standards to set up routine tests or create an advanced multi-stage test, all using the same program. Still picture and video capture are also included in the software as well as a powerful security and audit trail module to provide 100% traceability, full automation capability for automatic testing and much more.

mt
NEXYGEN™ MT Materials Test and Data Analysis Software and
Ondio™ Application Builder Software

NEXYGEN™ MT material test and data analysis software and Ondio application bulider software packages can be used with all Lloyd Instruments LR Series materials testing machines.  Please click here to contact us for more details on these packages.

Availible for Legacy Products. Contact us for more information!

Shimadzu Universal Testing Machines (Material Testers)
agsx AGS-X

The AGS-X is the descendent to the AGS-J. The AGS-X is a fine tester for Rubber, Plastic, and Film industries. It allows for efficient, powerful tensile and compression tests and also can perform bending tests of thermostatic resin, peeling testing and the plastic 3 point bending test.

  • Top-end machine performance from a table-top tester
  • Force 1/500 to 1/1
  • High speed return
  • 1 msec sampling
  • Touch load functionality
  • Capacity 1N to 10kN



agx AG-X

The AG-X Autograph testing machine, makes measurement a breeze while providing precise, high-speed results. It is ideal for a variety of industries, for QA/QC or R&D testing of plastics, metals, and other component parts.

  • Test force measurement precision of 1/1000 ±0.5%
  • Highly rigid, large-capacity load cells and testing jigs
  • 5kHZ sampling rate
  • 1 M pulse/second resolution
  • Up to 7 analog input channels
  • Increased linearity, as well as lateral and torsional rigidity
  • Capacity: 10N to 350kN



EZ Graph

Engineered for precise, high-speed testing of precision parts, medical devices, & electronic components, Shimadzu's space-saving EZGraph enables precise measurements of various materials utilizing a wide range of test speeds.

  • High Speed data sampling: Selectable from 1.25msec (for 25 seconds) to 5msec intervals
  • Wide range of test speeds: 0.00005 to 1000 mm/min, and crosshead speed precision of ±0.1%.
  • Capacity: 1N to 10kN

ez test



EZ Test Series

Applications vary but can include foods, pharmaceuticals, cosmetics, precision and electronic parts and education.

EZ-L

  • Load Capacity: 500N
  • Accuracy: Within +/-1% of indicated value( in the range1/1 to 1/250 of load cell rated capacity)
  • Crosshead Speed Range: 0.05mm/min. to 1000mm/min.

EZ-S

  • Load Capacity: 5kN
  • Accuracy: Within +/-1% of indicated value( in the range1/1 to 1/250 of load cell rated capacity)
  • Crosshead Speed Range: 0.05mm/min. to 1000mm/min.
uhx UHX/FX Series

The UH-X/FX Series is a new hydraulic universal testing machine which realized ease-of-operation for beginners, high precision testing control, and energy-saving by environmentally friendly design.

UH-X

  • 200kN to 4000kN frame capacity
  • Large-sized LCD touch screen
  • High precision control with closed loop system
  • USB Memory

UH-FX

  • 300kN ro 4000kN
  • Large-sized LCD touch panel to simplify operations and enhance visibility
  • Various automatic control programs are standard functions
  • Force auto-zero and auto-calibration functions
  • Non-revolving screw rod to improve safety
  • USB Memory
Shimadzu Software
x Trapezium X

Preform high-efficency, continuous testing thanks to fast data searches and one-touch method selection. Trapezium X's visual wizard guidance ensures trouble-free entry of method settings.
